Customizable 1mm IR plastic silicon hermetic TO-CAN photodiode
This high speed and high sensitive PIN photodiode in a standard 3 plastic package. The epoxy package itself is an IR filter, spectrally matched to infrared emitting diode.

File Name : Format: Size:

Description Feedback
Features
High responsivity;
Low dark current;
High speed;
Low cost.

Applications
Industrial automatic control;
Optical measurement equipment;
Audio equipment, air conditioner.

Electro-Optical Parameters

Parameters

Symbol

Test conditions

Value

Unit

Detection range

λd

-

800 ~ 1150

nm

Detect area

Φ

-

1 x 1

mm

Responsivity

Re

λ=800nm

0.15

mA/mW

λ=940nm

0.5

λ=1100nm

0.2

Dark current

ID

VR=10V

10

nA

Open-circuit voltage

VOC

Ee=5mW/cm2, p=940nm

0.41

V

Short-circuit current

ISC

Ee=5mW/cm2, p=940nm

3

uA

Reverse light current

IL

Ee=5mW/cm2,p=940nm,VR=5V

3

uA

Rise time

TR

RL =1000Ω, VR =10V

5

ns

Reverse break voltage

VBR

IR=100uA

170

V

Junction capacitance

Cj

f=1MHz, VR=5V

5

pF

Operating voltage

VR

-

0-10

V

Package

black Plastic package 3


Package

Original Carton Package;
As customers‘ requirement.

Shipping
5-10 Working days after receive the payment;
Shipment: Air transportation(DHL / UPS / TNT / Fedex / EMS / CHINA POST);
Shipping fee depends on the weight and size.


Payment
For large orders: T/T, Credit card;
For small orders: Paypal are accepted.

Warranty
All products have been tested before shipping out;
All products have 1-3 years warranty.(After the quality guarantee period began to charge appropriate maintenance service fee.)

Refund & Replacement
We appreciate your business and offer an instant 7 days return policy. (7 days after receiving the items);
If the items you purchase from our store are not of perfected quality, that is they don‘t work electronically to manufacturers specifications, simply return them to us for replacement or refund;
If the items are defective, please notify us within 3 days of delivery;
Any items must be returned in their original condition to qualify for a refund or replacement;
The buyer is responsible for all the shipping cost incurred.
