SM Fiber coupled 1560.61nm 50KHz Narrow linewidth laser

The 50KHz narrow linewidth LD directly modulated external cavity laser is cost effective solution for 2.5 Gbits/s digital transmission in SMF-28 fiber. This is fabricated in a hermetically sealed 14-pin butterfly package that contains thermoelectric cooler (TEC), thermistor, monitor photodiode, optical isolator.

The narrow linewidth LD provides substantially lower dispersion penalty and lower chirp than a directly modulated DFB. The wavelength stability is assured by design, eliminating the need for wavelength lockers and complex feedback control circuits.

File Name : Format: Size:

Description Feedback

Features

ITU wavelengths across C-band;

100GHz channel spacing;

SONET/SDH OC-48/STM16 ring and meshed applications;

Low dispersion provides;

Low transient chirp provides unique narrow dynamic spectrum;

Excellent long-term wavelength stability eliminates the need for a wavelength locker.

Applications

Metro and Long Haul DWDM,100 GHz spaced networks;

SONET/SDH OC-48/STM16 ring and meshed applications;

Drop-side of DWDM long-haul transport equipment;

Optical Test and Instrumentation;

Microwave Photonics;

CATV networks.

Electro-Optical Parameters

Parameter	Symbol	Condition	Min.	Typ.	Max.	Unit
Center Wavelength	λc	TL=17～35℃ CW	1559.11	1560.61	1561.11	nm
Optical Output Power	P_O	-	5	-	-	mW
Spectral linewidth	LW	-	-	50	75	KHz
Side-mode Suppression Ratio	SMSR	CW	30	40	-	dB
Optical Isolation	-	-10 < TC < +70 ºC	30	-	-	dB
Relative Intensity Noise	RIN	CW, output power 5mW	-	-	-135	dB
Wavelength drift with case (-10 to 70 ºC) temperature	△λ	TEC temperature at 15℃ to 35℃	-	-	±30	pm
Wavelength Temperature coefficient	Δλ/ΔT	TEC temperature at 15℃ to 35℃	-	15	30	pm/ºC

Package

Original Carton Package;

As customers‘ requirement.

Shipping

5-10 Working days after receive the payment;

Shipment: Air transportation(DHL / UPS / TNT / Fedex / EMS / CHINA POST);

Shipping fee depends on the weight and size.

Payment

For large orders: T/T, Credit card;

For small orders: Paypal are accepted.

Warranty

All products have been tested before shipping out;

All products have 1-3 years warranty.(After the quality guarantee period began to charge appropriate maintenance service fee.)

Refund & Replacement

We appreciate your business and offer an instant 7 days return policy. (7 days after receiving the items);

If the items you purchase from our store are not of perfected quality, that is they don‘t work electronically to manufacturers specifications, simply return them to us for replacement or refund;

If the items are defective, please notify us within 3 days of delivery;

Any items must be returned in their original condition to qualify for a refund or replacement;

The buyer is responsible for all the shipping cost incurred.
