1064nm Narrow bandwidth FBG 600mW butterfly laser diode module

The next generation wavelength stabilized high power single mode 1064nm laser module has been designed as a light source for narrow bandwidth fiber laser and direct frequency conversion applications.

File Name : Format: Size:

Description Feedback

Features

FBG wavelength stabilized single mode laser;

CW or pulsed operation;

Operating temperature range -40℃ to +50℃;

Wavelength/temperature coefficient 0.01nm/℃;

Built-in monitor photodiode, thermo-electric cooler and thermistor;

Single mode or PM fiber pigtail (Corning HI1060, NA=0.14, MFD=6.2um@1060nm).

Applications

Fiber lasers;

Frequency conversion;

Spectroscopy.

Electro-Optical Parameters

Parameter	Symbol	Condition	Min.	Typ.	Max.	Unit
CW Operating power	P_O	I_OP = 1A	-	600	-	mW
Operating pulsed power	Pp	<500ns/500KHz	-	1.2	-	W
Operating pulsed current	I_P	<500ns/500KHz	-	-	2	A
Forward voltage	V_F	-	-	1.7	2.5	V
Peak wavelength	λ_C	pulsed operation	1063	1064	1065	nm
Spectral width(FWHM)	LW	-	-	0.15	0.3	nm
Pulse width	-	-	5	-	500	ns
Repetition rate	-	-	-	-	500	KHz
Duty cycle	T	-	-	-	5	%

Package

Original Carton Package;

As customers‘ requirement.

Shipping

5-10 Working days after receive the payment;

Shipment: Air transportation(DHL / UPS / TNT / Fedex / EMS / CHINA POST);

Shipping fee depends on the weight and size.

Payment

For large orders: T/T, Credit card;

For small orders: Paypal are accepted.

Warranty

All products have been tested before shipping out;

All products have 1-3 years warranty.(After the quality guarantee period began to charge appropriate maintenance service fee.)

Refund & Replacement

We appreciate your business and offer an instant 7 days return policy. (7 days after receiving the items);

If the items you purchase from our store are not of perfected quality, that is they don‘t work electronically to manufacturers specifications, simply return them to us for replacement or refund;

If the items are defective, please notify us within 3 days of delivery;

Any items must be returned in their original condition to qualify for a refund or replacement;

The buyer i
