200KHz 1550nm 10mW Narrow linewidth DFB laser
Narrow linewidth DFB laser diode in a butterfly -type 14 pin package with thermo-electric cooler and 30dB isolator.

File Name : Format: Size:

Description Feedback
Features
ITU wavelengths across C-band;
100GHz channel spacing;
SONET/SDH OC-48/STM16 ring and meshed applications;
Low dispersion provides;
Low transient chirp provides unique narrow dynamic spectrum;
Excellent long-term wavelength stability eliminates the need for a wavelength locker.

Applications
Metro and Long Haul DWDM,100 GHz spaced networks;
SONET/SDH OC-48/STM16 ring and meshed applications;
Drop-side of DWDM long-haul transport equipment;
Optical Test and Instrumentation;
Microwave Photonics;
CATV networks.

Electro-Optical Parameters

Parameter

Symbol

Condition

Min.

Typ.

Max.

Unit

Center Wavelength

λc

TL=17~35℃ CW

1548

1550

1552

nm

Optical Output Power

PO

-

10

-

-

mW

Spectral linewidth

LW

-

-

200

400

KHz

Side-mode Suppression Ratio

SMSR

CW

35

45

-

dB

Optical Isolation

-

-10 < TC < +70 ºC

30

-

-

dB

Relative Intensity Noise

RIN

CW, output power 5mW

-

-145

-

dB

Wavelength drift with case (-10 to 70 ºC) temperature

△λ

TEC temperature at 15℃ to 35℃

-

-

±0.1

pm

Wavelength Temperature coefficient

Δλ/ΔT

TEC temperature at 15℃ to 35℃

-

0.01

-

nm/ºC


Package

Original Carton Package;
As customers‘ requirement.

Shipping
5-10 Working days after receive the payment;
Shipment: Air transportation(DHL / UPS / TNT / Fedex / EMS / CHINA POST);
Shipping fee depends on the weight and size.


Payment
For large orders: T/T, Credit card;
For small orders: Paypal are accepted.

Warranty
All products have been tested before shipping out;
All products have 1-3 years warranty.(After the quality guarantee period began to charge appropriate maintenance service fee.)

Refund & Replacement
We appreciate your business and offer an instant 7 days return policy. (7 days after receiving the items);
If the items you purchase from our store are not of perfected quality, that is they don‘t work electronically to manufacturers specifications, simply return them to us for replacement or refund;
If the items are defective, please notify us within 3 days of delivery;
Any items must be returned in their original condition to qualify for a refund or replacement;
The buyer is responsible for all the shipping cost incurred.
