Polarization maintaining fiber patchcord jumper
The SC/FC/ST/LC fiber patch cords and pigtails use advanced equipment and the industry‘s most stringent production test standards, and their optical and mechanical properties meet Telcordia and IEC standards. With high-quality ceramic ferrules and high-quality fiber, the insertion loss is very small. It is suitable for use in high-demand optical fiber network environments such as telecommunications and broadcasting.

File Name : Format: Size:

Description Feedback
Features
Adopt the most advanced core adjustment technology in the industry;
No scratches on the end face, no dirt return loss;
Echo loss PC≥45dB, UPC≥50dB, APC≥60dB;
Insertion loss ≤0.2dB;
Strict environmental experiments to meet Telcordia standards;
Single mode (9/125um), multimode (62.5/125um and 50/125um), or single core, dual core;
Choice of PC type, UPC type or APC type.

Applications
Signal transmission and data transmission;
Telecommunications network, local area network (LAN), metropolitan area network, optical fiber communication system;
Fiber optic test instrument/instrument;
Fiber optic CATV, fiber optic sensor;
Fiber distribution frame, rack and wall-mounted fiber distribution unit.

Electro-Optical Parameters

Parameter

Unit

Value

Connector Type

-

FC/UPC, SC/UPC,LC/UPC,MU/UPC

Center Wavelength

nm

1310/1550

980/1060

850

780

Max. Insertion Loss

nm

0.3

0.5

0.8

0.8

Min. Extinction Ratio at 23℃

dB

23

23

22

22



Min. Return loss

UPC Type

dB

50

APC Type

dB

60

Fiber Type

-

PM Panda fiber

Key Orientation

-

Slow Axis

Tolerance for Axis Alignment

deg

±3

Operating Temperature

℃

-20~+70

Storage Temperature

℃

-40~+85


Package

Original Carton Package;
As customers‘ requirement.

Shipping
5-10 Working days after receive the payment;
Shipment: Air transportation(DHL / UPS / TNT / Fedex / EMS / CHINA POST);
Shipping fee depends on the weight and size.


Payment
For large orders: T/T, Credit card;
For small orders: Paypal are accepted.

Warranty
All products have been tested before shipping out;
All products have 1-3 years warranty.(After the quality guarantee period began to charge appropriate maintenance service fee.)

Refund & Replacement
We appreciate your business and offer an instant 7 days return policy. (7 days after receiving the items);
If the items you purchase from our store are not of perfected quality, that is they don‘t work electronically to manufacturers specifications, simply return them to us for replacement or refund;
If the items are defective, please notify us within 3 days of delivery;
Any items must be returned in their original condition to qualify for a refund or replacement;
The buyer is responsible for all the shipping cost incurred.
