Customize 850nm 5mW SLED superluminescent light emitting diode module
850nm High power SLED DIL package, Floating with external monitor photodiode.

File Name : Format: Size:

Description Feedback
Features
Wavelength 850nm;
Low spectralripple, Broad bandwidth;
Industry standard, 8-pins,14-pins butterfly package;
Built-in optical isolator;
Low polarization sensitivity.

Applications
Fiber optic communications system;
Fiber optic gyroscopes;
Fibe roptic sensors;
Optical test instruments;
Optical coherence tomography;
Biomedical imaging systems.

Electro-Optical Parameters

Parameter

Symbol

Min

Typ

Max

Unit

Operating Current

IF

0



140

mA

Power in SMF

Po

3

5



mW

Center Wavelength

λC

830

850

870

nm

Bandwidth FWHM



50

55



nm

Spectral ripple [RB=0.1nm]





0.1

0.2

dB

Monitor Diode Current

IMPD

50

200 (**)



mA

PD Monitor Bias Voltage

Vb

0



-10

V


Package

Original Carton Package;
As customers‘ requirement.

Shipping
5-10 Working days after receive the payment;
Shipment: Air transportation(DHL / UPS / TNT / Fedex / EMS / CHINA POST);
Shipping fee depends on the weight and size.


Payment
For large orders: T/T, Credit card;
For small orders: Paypal are accepted.

Warranty
All products have been tested before shipping out;
All products have 1-3 years warranty.(After the quality guarantee period began to charge appropriate maintenance service fee.)

Refund & Replacement
We appreciate your business and offer an instant 7 days return policy. (7 days after receiving the items);
If the items you purchase from our store are not of perfected quality, that is they don‘t work electronically to manufacturers specifications, simply return them to us for replacement or refund;
If the items are defective, please notify us within 3 days of delivery;
Any items must be returned in their original condition to qualify for a refund or replacement;
The buyer is responsible for all the shipping cost incurred.
